Figure 7. Fitting 314
Ford/Lincoln/Mercury – Fits earlier Ford, Lincoln, and
Mercury small and large passenger vehicles
Figure 9. Fitting 317 and Fitting 318
Any vehicle with 5/16 inch hose connections
Figure 11. Fitting 320 and Fitting 323
Any vehicle with 1/4 inch pipe fittings. Sometimes
used to bypass quick connect receptacles
Figure 13. Fitting 322
Mercedes Benz and some BMW
Figure 8. Fitting 315 and Fitting 316
Any vehicle with 1/4 inch hose connections
Figure 10. Fitting 319
Any vehicle with 3/8 inch hose connections
Figure 12. Fitting 321 and 324
Any vehicle with 1/2 inch hose connections
Figure 14. Hose Clamps in two sizes, three each
Blue
Band
FIT315
FIT316
YELLOW
FIT320 FIT323
FIT317
FIT318
BLACK
FIT321
BLACK
FIT324
