12
Removing Air From the Cylinder
When using the T-TECH for the first time, there may be
space at the top of the cylinder (air in the cylinder). If not
corrected, this condition may short future exchanges. If for
some reason the piston is at the bottom of the cylinder, or
there is large air pocket above the piston, the piston can be
moved to the top of the cylinder by the following method.
1.
Set CONTROL VALVE to SERVICE VEHICLE.
2.
Attach a service hose adapter to one of the service
transfer hoses.
3.
Insert an air nozzle into the end of the service hose
adapter.
4.
Control the air line at 10 psi (138 kPa) or less and
begin filling the bottom of the cylinder with air.
Service
Transfer
Hoses
Overflow
Tank
Service
Hose
Adapters
Figure 35. Hoses and Hose Adapters
