D14245.04—DECEMBER 2008 17
PrecisionHD 1080p Camera User Guide
Remote control
Inquiries
Command Command Packet Response
Gamma_Table_Inq 8x 09 04 52 ff Resp: y0 50 0p 0q 0r 0s ff
pqrs: Gamma table in use if
manual mode.
Call_LED_Inq 8x 09 01 33 01 ff Resp: y0 50 0p ff
p=2: On, p=3: Off, p=4: Blink
Power_LED_Inq 8x 09 01 33 02 ff Resp: y0 50 0p ff
p=2: On, p=3: Off
Video_System_Inq 8x 09 06 23 ff y0 50 0p 0q 0r 0s ff
pqrs=video mode currently
being output on the HDMI port.
See chapter on DIP switches.
DIP_Switch_Inq 8x 09 06 24 ff y0 50 0p 0q 0r 0s ff pqrs
contains the bit pattern of the
DIP switch. See chapter on DIP
switches.
IR_Output_Inq 8x 09 06 08 ff Resp: y0 50 0p ff
p=2: On, p=3: Off
ALS_RGain_Inq 8x 09 50 50 ff Ambient Light Sensor Resp: y0
50 0p 0q 0r 0s 0t 0u 0v 0w ff
pqrstuv=32 bit unsigned
integer, relative gain value. The
integration time is a constant
set in the camera SW.
ALS_BGain_Inq 8x 09 50 51 ff
ALS_GGain_Inq 8x 09 50 52 ff
ALS_WGain_Inq 8x 09 50 53 ff
BestView_Inq 8x 09 50 60 ff Resp: y0 50 0p 0q 0r 0s ff
pq=0: BestView not running.
pq>0: BestView running, time
specified when started
rs: Time spent so far
Up side down_Inq 8x 09 50 70 ff Resp: y0 50 0p ff
p=0: Camera is upright.
p=1: Camera is upside down.
Command Command Packet Response
CAM_ID_Inq 8x 09 04 22 ff Resp: 90 50 zz xx 00 yy ff
Only zz, which identifies the
camera, is relevant. zz = 0x50
for this camera.
CAM_SWID_Inq 8x 09 04 23 ff Resp: y0 50 [1-125 bytes ASCII
SWID] ff. Never route this
message through Sony cameras.
CAM_HWID_Inq 8x 09 04 24 ff The response is the Module
Serial Number stored in
EEPROM. The number is
converted to ASCII : y0 50 [12
bytes ASCII HWID] ff.
Zoom_Pos_Inq 8x 09 04 47 ff Resp: y0 50 0p 0q 0r 0s ff
pqrs: zoom position
Focus_Pos_Inq 8x 09 04 48 ff Resp: y0 50 0p 0q 0r 0s ff
pqrs: focus position
Focus_Mode_Inq 8x 09 04 38 ff Resp: y0 50 0p ff
p=2: Auto, p=3: Manual
PanTilt_Pos_Inq 8x 09 06 12 ff Resp: y0 50 0p 0q 0r 0s 0t 0u
0v 0w ff
pqrs: pan position tuvw:
tilt position
Power_Inq 8x 09 04 00 ff Resp: y0 50 0p ff
p=2: On, p=3: Off
WB_Mode_Inq 8x 09 04 35 ff Resp: y0 50 0p ff
p=0: Auto , p=6: Table manual
WB_Table_Inq 8x 09 04 75 ff Resp: y0 50 0p 0q 0r 0s ff
pqrs: Table used if table mode
AE_Mode_Inq 8x 09 04 39 ff Resp: y0 50 0p ff
p=0: Auto, p=3: Manual
Backlight_Mode_Inq 8x 09 04 33 ff Resp: y0 50 0p ff
p=2: On, p=3: Off
Mirror_Inq 8x 09 04 61 ff Resp: y0 50 0p ff
p=2: On, p=3: Off
Flip_Inq 8x 09 04 66 ff Is video flipped or not?
Resp: y0 50 0p ff
p=2: On , p=3: Off
Gamma_Mode_Inq 8x 09 04 51 ff Resp: y0 50 0p ff
p=2: Auto, p=3: Manual
