D14245.04—DECEMBER 2008 15
PrecisionHD 1080p Camera User Guide
Remote control
Camera commands
Command Command Packet Comments
Call_LED_On 8x 01 33 01 01 ff Refers to orange LED on top
of camera. Will always be off
at startup.
Call_LED_Off 8x 01 33 01 00 ff
Call_LED_Blink 8x 01 33 01 02 ff
Power_LED_On 8x 01 33 02 01 ff Green power LED. If switched
to off and stored to startup
profile, it will always be off.
Power_LED_Off 8x 01 33 02 00 ff
IR_Output_On 8x 01 06 08 02 ff See IR push message.
IR_Output_Off 8x 01 06 08 03 ff
IR_CameraControl_On 8x 01 06 09 02 ff Lets up/down/left/right/
zoom+/- on the IR remote
control the camera directly.
Those keycodes will be sent to
the controller if IR Output is on.
IR_CameraControl_Off 8x 01 06 09 03 ff
BestView_On 8x 01 50 60 0p 0q ff Turn BestView on or off.
pq=time (in seconds) Will
generate push message(s) as
specified above when the time
runs out.
BestView_Stop 8x 01 50 60 00 00 ff
Command Command Packet Comments
Power_On 8x 01 04 00 02 ff Power control. This command
stores the zoom and focus
value and reset these motors.
Used for Tiger if the camera
was on for a long time.
Power_Off 8x 01 04 00 03 ff
Video_Format 8x 01 35 0p 0q 0r ff Selects video format. p =
reserved. q = video mode. r =
See the chapter about the DIP
switch settings
WB_Auto 8x 01 04 35 00 FF WB: White Balance
WB_Table_Manual 8x 01 04 35 06 ff
WB_Table_Direct 8x 01 04 75 0p 0q 0r 0s ff Used if WBmode = Table
manual pqrs = wb table.
AE_Auto 8x 01 04 39 00 FF AE: Automatic Exposure.
AE_Manual 8x 01 04 39 03 FF
Iris_Direct 8x 01 04 4B 0p 0q 0r 0s FF Used if AE mode = Manual.
pqrs: Iris position, range 0..50
Gain_Direct 8x 01 04 4c 0p 0q 0r 0s FF Used if AE mode = Manual.
pqrs: Gain position, values:12-
21dB.
Backlight_On 8x 01 04 33 02 FF BacklightCompensation mode
Backlight_Off 8x 01 04 33 03 FF
Mirror_On 8x 01 04 61 02 ff Sony calls this CAM_LR_
Reverse. RR (FT/AT mirror
command)
Mirror_Off 8x 01 04 61 03 ff
Flip_On 8x 01 04 66 02 ff Sony calls this CAM_ImgFlip.
Flip_Off 8x 01 04 66 03 ff
Gamma_Auto 8x 01 04 51 02 ff Gamma mode. Default uses
gamma table 4.
Gamma_Manual 8x 01 04 51 03 ff
Gamma_Direct 8x 01 04 52 0p 0q 0r 0s ff pqrs: Gamma table to use in
manual mode. Range 0-7.
MM_Detect_On 8x 01 50 30 01 ff Turn on the Motor Moved
Detection (camera recalibrates
if touched)
MM_Detect_Off 8x 01 50 30 00 ff Turn off the Motor Moved
Detection (camera does not
recalibrate if touched)
