D14245.04—DECEMBER 2008 14
PrecisionHD 1080p Camera User Guide
Remote control
Network and interface commands
Command Set Command Packet Comments
IF_Clear 8x 01 00 01 ff Clear command buffer. Stop
any current operation in
progress. Does not do much
on Rover.
Address_Set 8x 30 0p ff p = address for this device. If
x=8 (broadcast), increase p
with 1 before sending to chain.
Command_Cancel 8x 2p ff p = Socket ID. Rover does
not support multiple sockets.
Commands will always run to
completion. Don’t use it
.
Push messages
Messages sent from camera to controller.
Command Set Command Packet Reply and Comments
Network_Change y0 38 ff This indicates that cameras
have been added to or
removed from the chain.
It is recommended to wait 9
seconds after receiving this
message before doing a full
reconfigure.
IR_Push y0 07 7d 02 gg hh ff If IR mode is on, IR codes
received by the camera will be
sent to the controller.
gg = IR ID
hh = keycode
BestView_Done_Push y0 0a 61 0p 0q ff First push message sent after
BestView is done.
pq = Number of frames
detected. The camera will
generate pq Res_Push
messages after this message.
BestView_Res_Push y0 0a 62 0p 0q [tiltpos] [panpos]
[tiltSize] [panSize] [yPos] [xPos]
[yDim] [xDim] [trackDur] [quality]
[speech] ff pq = Face number, should be
less than or equal to pq given in
Done_Push.
Parameters specified in
brackets are unsigned 16 bit
quantities, defined as “0p 0q
0r 0s”.
[tiltpos] and [panpos] are 16 bit
signed.
Make sure this message is not
routed through Sony cameras.
