http://www.tyan.com 14
2.6-E. FAN Headers (P0FAN, P1FAN, FAN1, FAN2, FAN3)
These headers allow for extra fans to be installed. P0FAN and P1FAN are reserved for CPU0 and CPU1
(respectively). All other fans are left to the user’s discretion.
2.6-F. Chassis Intrusion* Header (J90) (RESERVED)
This header is provided in the event that your chassis has a chassis intrusion feature*, and that an appli-
cation is available to manage this feature.
Specifications
12V Voltage
Amperage 300mA
P0FAN
FAN3
FAN1
FAN2
ground
1 2
+12V speed
3
FAN
NOTE:
The FAN connector has a 12V, 300mA limitation. Tyan takes no responsibility
and will not be held liable for damage related to the misuse of any FAN header.
J90
* Indicates an optional feature, may not be available on some Tiger MP models
P1FAN
