11
Fluid System
Method of Lubrication .......................................................................................................................Pump
Fluid Flow.............................................................................................................................................25 GPM
Total Fluid Capacity............................................................................................................................38 Gallons
Reservoir Capacity..............................................................................................................................34 Gallons
Reservoir Volume ................................................................................................................................20.8 Cubic Feet
Normal Discharge Temperature.........................................................................................................190°F
HAT Shutdown Temperature ............................................................................................................250°F
Fluid Carryover Rate (unloaded).......................................................................................................2 PPM
Standard Fluid......................................................................................................................................QUINSYN
®
Air-cooled Data
Maximum Heat Rejection....................................................................................................................2,387 BTU/min.
Cooling Fan Static Pressure...............................................................................................................0.125" wc
Fan Motor.............................................................................................................................................3 HP
Fan RPM ...............................................................................................................................................1,200
Fan Flow...............................................................................................................................................10,000 CFM
Water-cooled Data
Water Flow – 50°F...............................................................................................................................5 gal./min.
Water Flow – 70°F...............................................................................................................................7 gal./min.
Water Flow – 90°F...............................................................................................................................12 gal./min.
Maximum Water Temp. Rise @ 1 GPM ............................................................................................57.2°F
Recommended Water Pressure .........................................................................................................100 psig
Water Pressure Drop @ Max. Flow..................................................................................................7 psi
Water Connections .............................................................................................................................1" NPT
Sound Level
Unenclosed – Air ................................................................................................................................93 dB (A)
Unenclosed – Water...........................................................................................................................88 dB (A)
Standard Enclosure – Air...................................................................................................................87 dB (A)
Standard Enclosure – Water..............................................................................................................85 dB (A)
Low Sound Enclosure.........................................................................................................................86 dB (A)
Maximum Dimensions
Length ...................................................................................................................................................96"
Width ....................................................................................................................................................56"
Height....................................................................................................................................................73"
Weight ..................................................................................................................................................3,975 lbs.
