Names
o
f par
ts a
nd fun
c
tion
s
Basic guid
e
2
3
4
5
6
7
9
0
a
b
c
h
d
1
f
g
e
j
i
k
8
1 Mode dial ...................................... gP. 10
2 LCD monitor ............................ gP. 22, 24
3 MENU button ............................... gP. 20
4 INFO (Information display) button
................................................ gP. 23, 79
5 Tripod socket
6 Battery/card compartment cover ..... gP. 3
7 Battery/card compartment lock ....... gP. 3
8 Accessory port ............................ gP. 132
9 D (Erase) button .......................... gP. 88
0 q (Playback) button ............. gP. 14, 77
a AEL/AFL button .................... gP. 44, 96
0 (Protect) button ..................... gP. 87
b < button ...................................... gP. 97
c Speaker
d Sub dial (j) ......................... gP. 15, 25
e Connector cover
f Card access lamp ................. gP. 12, 119
g Multi-connector ............. gP. 83, 112, 117
h HDMI mini-connector .................... gP. 84
i Main dial ( j) ......................... gP. 15, 25
j Arrow pad ( k) ................. gP. 15, 20, 25
Press the main dial in the following places.
Up: f
Down: g
Left: h
Right: i
k i button ....................................... gP. 20
