Page 22
22
Connecting the DV-SP506
—Continued
■
Connection method
3
3
3
3
(For more information on the audio settings for this connection method, see connection method
3
Note:
• Alternatively, the video signal can be fed directly to a TV by using a composite video, S-Video, or component video
cable, whichever is suitable for the TV’s inputs.
The video signal is fed to the AV receiver via a composite video, S-Video, or component video cable. The audio signal
is fed to the AV receiver via a digital or analog audio cable.
COAXIAL
DIGITAL
AUDIO OUTPUT
OPTICAL
AUDIO OUTPUT
SURR1
ANALOG
CENTER
1
L
R
L
R
2
D. MIX/
FRONT
SUB
WOOFER
SURR
CENTER
FRONT
SUB
WOOFER
COAXIAL IN
OPTICAL IN
S VIDEO IN
VIDEO IN
S VIDEO
VIDEO
VIDEO OUTPUT
COMPONENT
Y
COMPONENT
VIDEO IN
P
R
P
B
Y
P
R
P
B
Use any one of these con-
nections for the video signal.
Video
AV receiver
Select the analog or
digital input on your
AV receiver.
Audio
Audio
Connect either one.
Speakers
