SPECIFICATIONS
14" (34 cm "V") measured diagonally
90 degrees deflection
Electronic Tuner
VHF: 0-S41
UHF: 21 - 69
VHF/ UHF 75 ohm unbalanced
1.5 W (max)
3.8 x 6.4 cm 8 ohm
5°C to 40°C
CCIR 625 Lines 50 Fields
PAL B/G
VHS, 2 Rotary Heads Helical Scanning System
Luminance: FM azimuth recording
Color signal: converted sub-carrier phase shift recording
Video: 4 Rotary Heads
Audio/Control: 1 Stationary Head
Erase: 1 Full Track Erase
1 Track
12.65mm high density tape
Approx. 1 minutes 48 seconds (With E-180 Cassette Tape)
SP: 23.39 mm/s, LP: 11.69 mm/s (NTSC SP: 33.35 mm/s)
SP: 300 min.with E-300 video cassette (PAL)
LP: 600 min.with E-300 video cassette (PAL)
210 min.with T-210 video cassette (NTSC)
SP 5 & 7 x Normal Speed
LP 7 & 13 x Normal Speed
Video: 1.0 Vp-p 75 ohm unbalanced
Audio: 500 mV, 50k ohm unbalanced
Video: 1.0 Vp-p 75 ohm unbalanced
Audio: 500mV, 1k ohm unbalanced
AC 240V, 50Hz
50 W
11.0 kg
362(W) x 382(H) x 367(D) mm
DC 3V (Two batteries, AAA/ R03/ UM-4)
Remote Control unit
2 Batteries (AAA/ R03/ UM-4)
Telescopic Antenna with 300-75 ohm matching transformer
21 Pin-RCA Cable
14VROT 20VROT
20" (48 cm "V") measured diagonally
90 degrees deflection
TELEVISION
Picture Tube:
Tuner:
Receiving Channels:
Antenna Input:
Audio Output Power:
Speaker:
VCR
Operating Temperature:
Television System:
Video Recording System:
Head:
Audio Track:
Tape Format:
F. FWD/REW Time at 25°c:
Tape Speed:
Play Back/Recording Time:
Play Back Time:
Speed Search:
Input Level:
Output Level:
GENERAL
Power Source:
Power Consumption:
Weight:
Dimensions:
REMOTE CONTROL UNIT
Power Supply:
ACCESSORIES
2.5 W (max)
7.6 cm 8 ohm
60 W
19.0 kg
489(W) x 484.5(H) x 465(D) mm
Weight and Dimensions are approximate. Because we continually strive to improve our products we
may change specifications and designs without prior notice.
