80
A
ppe
nd
ic
es
Spe
c
ifica
tions
a
nd
Dime
nsions
V400-H111/211
User’s Manual
Appendices
V400-H111 V400-H211
Field of vision 5 to 10 mm 15 to 30 mm
Working distance 40 mm (contact with the code when the Contactor is mounted)
Power supply voltage 5 VDC ± 10 %
Current consumption 1 A max.
Serial interface RS-232C
Applicable code DataMatrix ECC200 10 × 10 to 64 Ч 64, 8 Ч 18 to 16 × 48
QR Code Model 1.2 21 × 21 to 57 × 57 (Ver. 1 to 10)
Operating method Pushbutton control using the trigger buttons
System Settings Operation in the Setup window (on Code Reader), uploading setting data using
a Memory Card, or communication by “2DCR Configear”
Memory Card SD card
Monitor 1.8-inch TFT liquid crystal display for displaying image and read data
Indicators Power indicator and Memory Card access indicator
Ambient temperature Operating: 0 to 40°C Storage: -25 to 60°C
Ambient humidity 35% to 85%(with no condensation)
Ambient environment No corrosive gases
Vibration resistance 10 to 150 Hz ; half-amplitude: 0.35 mm (max. acceleration: 50 m 2 /s)
Shock resistance 150m 2 /s 3 times in 6 directions
Weight Approx. 230 g
Degree of protection IEC 60529 (IP64)
Materials Case: ABS; Optical surface: PC; Display: PMMA
