49
V400-H111/211
User’s Manual
Section 4
Ma
king
Sett
ings
on
t
h
e
Ma
in
Bod
y
Section 4
System Settings
Changing Communication Conditions
1.
Select [Communication] in the Setup window.
The Setup Communication window appears.
2.
Select the item to be changed.
The cursor moves to the right of the selected item.
3.
Change the setting.
Available settings are shown in the table below. After a new setting is selected,
the cursor moves to the item field.
The default settings are indicated with an asterisk.
Setting item Settings
Baud rate (BaudRate) 9,600 * , 19,200, or 38,400
Parity None * /Odd/Even
Data length (DataLength) 7bits or 8 bits *
Stop Bit (StopBit) 1 bit * or 2 bits
Header (Prefix) None * /STX/ESC
Footer (Suffix) ETX/LF/CR * /CR+LF
FCS ON or OFF *
