Manual No. 25-NFT1121-01
Series NFT-1121/2135 Mini CCD Fixed Position Scanners
21. Buzzer Operation
* These commands are useful in verifying that proper communication exists between the scanner and the
host. They can be invoked only via computer commands.
CONTINUED ON NEXT PAGE
Page 44
Computer
Command
Function
/Description
Bar Code
Command
(Z7)
START/END
Programming Menu
,Z7,
T0 Volume = Maximum
,T0, B
T1 Volume = Upper Mid-range
,T1,
T2 Volume = Lower Mid-range
,T2,
T3 Volume = Minimum
,T3,
T4 Disable hardware buzzer
,T4,
T5 Enable hardware buzzer
,T5,
V5
Ring software buzzer once at
3kHz for 200 Ms
Use
Computer Command *
V6
Ring software buzzer once at
3kHz, 2kHz interval for 200 mS
Use
Computer Command *
V7
Ring software buzzer once at
2kHz, 3kHz interval for 200 mS
Use
Computer Command *
W0 Disable software buzzer
,W0,
W1 Enable software buzzer at 3kHz
,W1,
W2
Enable software buzzer at 3kHz
with 2.5kHz interval
,W2, B
