Manual No. 25-NFT1121-01
Series NFT-1121/2135 Mini CCD Fixed Position Scanners
20. Handshaking
* Use Z2 Computer Command to store in memory prior to power off.
Page 43
Computer
Command
Function
/Description
Bar Code
Command
(Z7)
START/END
Programming Menu
,Z7,
(I0)
Wait for CTS from terminal
= Unlimited
,I0,
(I1)
Wait for CTS from terminal
= 100 mS
,I1,
(I2)
Wait for CTS from terminal
= 200 mS
,I2,
(I3)
Wait for CTS from terminal
= 400 mS
,I3,
(I4)
ACK/NAK Delay Time
Unlimited
,I4,
(I5)
ACK/NAK Delay Time
= 100 mS
,I5,
(I6)
ACK/NAK Delay Time
= 500 mS
,I6,
(I7)
ACK/NAK Delay Time
= 1000 mS
,I7,
(P0) No Handshaking *
,P0, B
(P1) Busy/Ready *
,P1,
(P2) Modem *
,P2,
(P3) ACK/NAK *
,P3,
(P4) ACK or No response NAK *
,P4,
(P5) No ACK/NAK *
,P5,
