Manual No. 25-NFT1121-01
Series NFT-1121/2135 Mini CCD Fixed Position Scanners
Section 4
Configuring the Scanner
Since the operation of the NFT-1125/2135 Series scanner is microprocessor controlled, it is possible to modify
or program its operation to match your specific application. Changes in parameter settings can be changed or
programmed in two ways. The first method employs specially designed programming bar codes which
instruct the scanner to modify specific parameters. The second is to program the scanner by sending software
instructions from the host PC to the scanner via the RS232 connection.
Programming Menus & Commands
Appendix A contains full instructions on how to configure the scanner as well as a complete listing of the
computer commands and programming bar codes that are available to customize the scanner for your
application.
Default Settings
When you modify or change any parameters, the scanner can be programmed to retain the new parameter in
memory, even if power interrupted or terminated. If for any reason, however, the scanner is instructed to
return all parameters to default settings (U4), it will return to the factory default settings shown in the
following table.
Page 13
Parameter Factory Default Setting
RS 232 Communications 9600 baud
8 data bits
1 stop bit
No parity
No handshaking
Trigger Function Disabled
Read Mode Multiple Read Mode
No. of Redundant Decodes Two
Bar Code Symbologies All Symbologies enabled
UPC-A (13 digits) Add leading zero
Enable check digit
UPC-E (7 digits) Add leading zero
Enable check digit
Code 39 Do not calculate check digit
Enable start/stop characters (*.....*)
Disable character length of one
Codabar Enable start/stop characters as abcd/abcd
Do not calculate check digit
Disable character length of one
2 of 5 Do not calculate check digit
Disable characters length of two
Fixed length of bar code only Disabled
Software buzzer Disabled
Positive bar codes only Enabled
Error indications Do not transmit error code
Print quality adjustment Output from Low or High analog gain
1 MHz sampling rate
