Getting Started
3-1
3
3.1 Attaching the Pump
3.1.1 Introduction
There are five possible mounting configurations for using the peristaltic pump
motor. Table 3-1 describes these mounting configurations.
Table 3-1. Pump Motor Mounting Configurations
Number of Pumps on Number of Pumps on Reference Section
Left Side Right Side
1 0 3.1.2
0 1 3.1.2
2 0 3.1.3
0 2 3.1.3
1 1 3.1.2
Your pump motor is equipped with a safety cover for whichever side of the
motor is not being used.
You must remove the safety cover before attempting to attach pump(s) to the
side.
NOTE
