Onkyo TX-8011 - Manual (Page 23)

23
Specifications
Amplifier Section
Power Output Front L/R
50 W + 50 W
(8
Ω
, 20 Hz–20 kHz, FTC)
Dynamic Power 105 W + 105 W (4 Ω )
70 W + 70 W (8 Ω )
THD (Total Harmonic Distortion)
0.08 % (Power Rated)
Damping Factor 60 (Front, 1 kHz, 8 Ω )
Input Sensitivity and Impedance
150 mV/50 k
Ω
(LINE)
2.5 mV/50 k
Ω
(PHONO MM)
Output Level and Impeadance
150 mV/2.2 k
Ω
(REC OUT)
Phono Overload 120 mV (MM 1 kHz 0.5 %)
Frequency Response 10 Hz–100 kHz/+1 dB –3 dB
(TONE FLAT, CD, TAPE-1,
TAPE-2/MONITOR)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
SN Ratio 100 dB (LINEIHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4 Ω
Tuner Section
FM
Tuning Frequency Range
87.5 MHz–108.0 MHz
Usable Sensitivity Stereo 17.2 dBf 2.0 µV(75 Ω IHF)
Mono 11.2 dBf 1.0 µV(75
Ω
IHF)
S/N Ratio Stereo 70 dB (IHF-A)
Mono 76 dB (IHF-A)
THD Stereo 0.25 % (1kHz)
Mono 0.15 % (1kHz)
Frequency Response 30 Hz–15 kHz/±1.5 dB
Stereo Separation 45 dB ( 1kHz )
AM
Tuning Frequency Range
530 kHz–1710 kHz
Usable Sensitivity 30 µV
S/N Ratio 40 dB
THD 0.70%
General
Power Supply AC 120 V, 60 Hz
Power Comsumption 180 W
Stand-by Power Comsumption
1.35 W
Dimensions(W x H x D)
17-1/8" x 5-7/8" x 12-11/16" inches
435 x 150 x 322 mm
Weight 16.3 lbs
7.4 kg
Analog Inputs PHONO, CD, TAPE-1, TAPE-2/
MONITOR
Analog Outputs TAPE-1, TAPE-2/MONI
Speaker Outputs 4(SP-A, SP-B)
Phones 1
Specifications and features are subject to change with-
out notice.
