Manual No. 25-ULNFT2100-01; Mar, 2005 NFT 2100 CCD Fixed Mount Barcode
Scanner
Page 20
Prefix Suffix Select Symbology for
prefix/Suffix
M5 O5 Codabar (NW-7)
M6 O6 Industrial 2 of 5
Prefix Suffix Select Symbology for
prefix/Suffix (cont.)
M7 O7 Interleaved 2 of 5
M8 O8 Code 93
M9 O9 Code 128
I8 I9 IATA
N0 N5 MSI/Plessey
MB OB SCode
L8 L9 Telepen
MZ PS Preamble/Postamble
Direct Input Alpha/Numeric Characters
Cmd Char. Cmd Char. Cmd Char.
Q0 0 0A A $A a
thru thru thru thru thru thru
Q9 9 0Z Z $Z z
Direct Input ASCII Control Characters
Cmd. Char. Cmd. Char. Cmd Char.
9G null 1K VT 1V SYN
1A SOH 1L FF 1W ETB
1B STX 1M CR 1X CAN
1C ETX 1N SO 1Y EM
1D EOT 1O SI 1Z SUB
1E ENQ 1P DLE 9A ESC
1F ACK 1Q DC1 9B FS
1G BEL 1R DC2 9C GS
1H BS 1S DC3 9D RS
1I HT 1T DC4 9E US
1J LF 1U NAK 9F
DEL
Direct Input Miscellaneous Characters
Cmd. Char. Cmd. Char. Cmd Char.
Direct Input Miscellaneous Characters
5A
E)
5M , 7A [
5B ! 5N - 7B \
5C “ 5O . 7C ]
5D # 5P / 7D ^
5E $ 6A : 7E _
5G & 6B ; 7F ‘
5H ` 6C < 9T {
5I ( 6D = 9U |
5J ) 6E > 9V }
5K * 6F ? 9W ~
5L + 6G @
Communication Parameters
K0 150 baud
K1 300 baud
K2 600 baud
K3 1,200 baud
K4 2,400 baud
K5 4,800 baud
K6 9,600 baud
K7 19,200 baud
K8 38,400 baud
L0 7 Data Bits
L1 8 Data Bits
L2 Parity = None
L3 Parity = Even
L4 Parity = Odd
L5 1 Stop bit
L6 2 Stop bits
Communication Handshaking
I0 Unlimited wait for CTS from terminal
I1 100 mS wait for CTS from terminal
I2 200 ms wait for CTS from terminal
I3 400 mS wait for CTS from terminal
P0 No Handshaking
