Manual No. 25-ULNFT2100-01; Mar, 2005 NFT 2100 CCD Fixed Mount Barcode
Scanner
Page 18
Appendix B
Computer Programming Commands
All commands listed below must be preceded by an 'ESC' (x1B) or 'STX' (x02) character and be followed
by a 'Carriage Return' (x0D) or 'ETX' (x03) character. Shaded areas indicate factory default settings.
Enable Disable Global Defaults
U2 Enable Factory Default Settings
Z1 Transmit software version
Z2 Save all values set by command
Z3
Display software setting flags,
prefix/suffix, & min/max lengths.
Only Add Symbology Selection
A0 Enable all symbologies
B0 Disable all symbologies
J0 Enable all UPC and EAN plus add-ons
A2 B2 Code 39
A3 B3 Codabar (NW-7)
A4 B4 IATA
A5 B5 Code 93
A6 B6 Code 128 (Inc. EAN-128)
A7 B7 MSI/Plessey
A1 B1 UK/Plessey
A9 B9
Telepen
J1 R1 UPC (A/E)
J2 R2 UPC (A/E)+2
J3 R3 UPC (A/E)+5
J4 R4 EAN (13/8)
J5 R5 EAN (13/8) +2
J6 R6 EAN (13/8) +5
J7 R7 2 or 5 Industrial
J8 R8 2 or 5 Interleaved
JD JZ TriOptic
RA R9 SCode
Enable Disable Options for UPC-A and UPC-E
E2 UPC-A as EAN13 (13 Digits)
Transmit leading zero & CD
E3 UPC-A (12 Digits) No leading zero
but transmit CD
E4 UPC-A as EAN13 (12 Digits)
Transmit leading zero but No CD
E5 UPC-A (11 Digits) No leading zero
& no CD transmitted
E6 UPC-E (8 Digits)Transmit leading
zero & CD
E7 UPC-E (7 Digits) No leading zero
but transmit CD
E8 UPC-E (7 Digits) Transmit leading
zero but no CD
E9 UPC-E (6 Digits) No leading zero
& no CD transmitted
6P 6Q Transmit UPC-E as UPC-A
Enable Disable Options for EAN-8 & EAN-13
6K 6J EAN-13 Transmit CD
6I 6H EAN-8 Transmit CD
IA IB Enable ISBN translation
HO HN Enable ISSN translation
Enable Disable Options for Code 39
8E
Enable read of 1 or more
character lengths
8D
Enable read of 3 or more
character lengths
C0 C1 Enable Check Digit calculation
D9 D8* Enable Check Digit Transmission
D0 D1
Enable start/stop characters
transmission (*…..*)
-Y
Enables primary decode
algorithms for Code 39, I & D 2 of
