34
7.Optional Parts
7. Optional Parts
Using the Optional AC Adapter
Insert batteries into the battery compartment even when using
the AC adapter.
Notes:
• Never unplug the power cord with wet hands.
• Use only the original AC adapter designed for this unit. Use of
unsupported adapters may damage the unit.
• When storing the optional AC adapter with the main unit, be
careful not to damage the main unit or cuff.
1. Insert the AC adapter plug
into the AC adapter jack on
the rear side of the main unit.
2. Plug the AC adapter into an
electrical outlet.
To disconnect the AC adapter, unplug the AC adapter from the
electrical outlet first and then immediately remove the AC
adapter plug from the main unit.
Medium Arm Cuffs
Arm circumference 22 - 32 cm
Large Arm Cuff
Arm circumference 32 - 42 cm
AC Adapter “Q”
CM1-7935058-8
CM-4997086-7
CL-4997065-4 Q Adapter-1098336-8
