Chapter 1: Installation
2. Align the wide bank of pins (1) on the Hard Disk—CAREFUL! The pins (2) in a separate
group on the Hard Disk are not used to make the connection—with the connector on the
control board, then gently slide the Hard Disk down to seat the pins firmly in the connector.
3. Align the hole in the Hard Disk bracket with the hole in the controller board, and insert the
included plastic rivet (1) through the aligned holes (2).
