Manual-7

Table 1. MRP Binary Control

Paging

Binary

Normal

Figure 10. SRM Exchange Software & DSC 1

DSC 1 & SRM Exchange Software

The optional Rane DSC 1 accessory provides a bridge to

connect a PC’s RS-232 port and the SRM 66’s RIP (Remote
Interface Port). Coupled with the included SRM Exchange
Software, the DSC 1 allows the exchange of settings between
an SRM 66 and the PC’s SRM Exchange software. Once the
settings are obtained by the PC they can be manipulated,
stored in a file, printed for future reference or sent to subse-
quent SRM 66s. SRM Exchange software can be downloaded
from www.rane.com allowing SRM 66 programming
“offline” without an SRM 66 present. However, the DSC 1 is
required to download such settings to the SRM 66.

For programming the Memory Recall Port using the Edit

MRP button, see RaneNote 142 “Advanced Applications for
the Ingenious SRM 66.”
