Chapter 6. Troubleshooting
6.1 Flowchart to Remedy the Troubles
Figure 6.1 shows the flowchart to remedy the troubles from when power to the emulator is activated
until the emulator debugger starts up. Check this while the target system is disconnected.
Figure 6.1 Flowchart to remedy the troubles
LED status not normal
LED status normal
Display not normal.
Error displayed.
Display normal
Display not normal.
Error displayed.
Display normal
Turning on the power of the PC4701
Program window of emulator debugger displayed
Front panel LED status of
the PC4701
Init dialog box of emulator
debugger displayed
1. Check emulator system connections.
See, "3.3 Connecting the PC4701 and Emulation Pod"
(page 26).
2. Redownload the firmware.
See "4.2 Downloading Firmware" (page 32).
3. Restart the PC4701 system.
EMEM dialog box of emulator
debugger displayed
See "6.2 (3) Errors Occur at Debugger Startup (target not
connected)" (page 45).
1. Check the operating environment etc. of the emulator debugger.
See the user's manual of the emulator debugger.
2. Reinstall the emulator debugger.
