C Controlled Register Bit Map (cont.)
Byte12 Control Register
Bit
Description
Contents
Type
Default
Note
7
Reserved
R/W
0
6
Reserved
R/W
0
5
Reserved
R/W
0
4
Reserved
R/W
0
3
Reserved
R/W
0
2
PLL1 Output (VCO1) Frequency
Control Bit
(M1/N1 Divider Control Bit)
PLL1 : for SRC/3V66/PCI_PLL
0 = Normal mode
PLL1 M1[6:0] and N1[9:0] are
changed on Table 5 selection
decided by FS4/3/2/A/B or
B9[5:1]
1 = Over or Down clocking mode
PLL1 M1[6:0] and N1[9:0] are
changed by B12[1:0], B13[7:0]
and B14[6:0].
B12[1:0], B13[7:0] and B14[6:0]
are able to be changed at B12[2]
= 1.
R/W
0
1
PLL1 N1 Divider Control Bit9
N1[9]
R/W
0
0
PLL1 N1 Divider Control Bit8
N1[8]
R/W
0
See.
Note
1
Note:
1. B12[1:0], B13[7:0] and B14[6:0] must be written together (at writing B14) in every case.
Byte13 Control Register
Bit
Description
Contents
Type
Default
Note
7
PLL1 N1 Divider Control Bit7
N1[7]
R/W
0
6
PLL1 N1 Divider Control Bit6
N1[6]
R/W
1
5
PLL1 N1 Divider Control Bit5
N1[5]
R/W
0
4
PLL1 N1 Divider Control Bit4
N1[4]
R/W
0
3
PLL1 N1 Divider Control Bit3
N1[3]
R/W
1
2
PLL1 N1 Divider Control Bit2
N1[2]
R/W
0
1
PLL1 N1 Divider Control Bit1
N1[1]
R/W
1
0
PLL1 N1 Divider Control Bit0
N1[0]
R/W
1
See
Note
1
Note:
1. B12[1:0], B13[7:0] and B14[6:0] must be written together (at writing B14) in every case.
