C Controlled Register Bit Map (cont.)
Table6 Clock Frequency Function Table
FS_4 FS_3 FS_2 FS_A FS_B No.
B9[5] B9[4] B9[3] B9[2] B9[1]
CPU
[MHz] SRC
[MHz] 3V66
[MHz] PCI
[MHz]
0 0 0 0 0 0 100.02 100.02 66.68 33.34
1 0 0 0 0 1 200.03 100.02 66.68 33.34
2 0 0 0 1 0 133.36 100.02 66.68 33.34
3 0 0 0 1 1 166.69 100.02 66.68 33.34
4 0 0 1 0 0 200.03 100.02 66.68 33.34
5 0 0 1 0 1 400.07 100.02 66.68 33.34
6 0 0 1 1 0 266.71 100.02 66.68 33.34
7 0 0 1 1 1 333.39 100.02 66.68 33.34
8 0 1 0 0 0 138.69 100.02 66.68 33.34
9 0 1 0 0 1 142.25 100.02 66.68 33.34
10 0 1 0 1 0 145.80 100.02 66.68 33.34
11 0 1 0 1 1 149.36 100.02 66.68 33.34
12 0 1 1 0 0 152.91 100.02 66.68 33.34
13 0 1 1 0 1 156.47 100.02 66.68 33.34
14 0 1 1 1 0 160.03 100.02 66.68 33.34
15 0 1 1 1 1 163.58 100.02 66.68 33.34
16 1 0 0 0 0 167.14 100.02 66.68 33.34
17 1 0 0 0 1 170.70 100.02 66.68 33.34
18 1 0 0 1 0 174.25 100.02 66.68 33.34
19 1 0 0 1 1 177.81 100.02 66.68 33.34
20 1 0 1 0 0 181.36 100.02 66.68 33.34
21 1 0 1 0 1 184.92 100.02 66.68 33.34
22 1 0 1 1 0 186.70 100.02 66.68 33.34
23 1 0 1 1 1 189.36 100.02 66.68 33.34
24 1 1 0 0 0 192.03 100.02 66.68 33.34
25 1 1 0 0 1 194.70 100.02 66.68 33.34
26 1 1 0 1 0 197.37 100.02 66.68 33.34
27 1 1 0 1 1 200.03 100.02 66.68 33.34
28 1 1 1 0 0 202.70 100.02 66.68 33.34
29 1 1 1 0 1 205.37 100.02 66.68 33.34
30 1 1 1 1 0 208.03 100.02 66.68 33.34
31 1 1 1 1 1 210.70 100.02 66.68 33.34
