RCA RTDVD1 - Manual (Page 17)

Operating Your Receiver
EN
13
Switching on /off
• To switch on the receiver, press POWER button on the
receiver once to enter standby mode. Press SOURCE
button on the receiver or one of the source buttons on the
remote control to power on the receiver. (See illustration
below)
• Standby: when the receiver is on, press the
ON/OFF on the remote to return to standby mode.
• To switch off the unit completely, press the POWER
button on the receiver.
Selection of Audio/Video source
When one of the audio/video source is selected, the audio
and video input corresponding to the name will be
activated.
The receiver acts as a switching device between all the
sources that are plugged into it.
Example 1:
If you connect a VCR player to the VCR input (audio +
video) on the receiver and press the SOURCE button
until VCR1/ANL shows on the display. You will be able to
have the sound and image transmitted by the VCR.
Example 2:
Based on example 1, the VCR input is selected. If SAT is
selected, image and sound from the SAT receiver source
will replace the VCR.
NOTE
Your receiver has a back up memory to keep your
settings like preset radio station for about 2 weeks
in case electricity cut occurs. If the receiver is
unplugged for more than 2 weeks, all the settings
will be lost and re-setting will be necessary.
PRE
POWER
SURROUND
ER
SOURCE
PRESET - PRESET +
TV VCR 1
VCR 2 DVD
/ C H +
T APE CD
SA T•CABLE AM•FM
ON OFF
VCR 1
VCR 2 DVD
/ C H +
CD
AM•FM
ON OFF TV
T APE
SA T•CABLE
SURROUND
WER
SOURCE
PRESET - PRESET +
SURROUND
ER
SOURCE
PRESET - PRESET +
VCR 1
VCR 2 DVD
/ C H +
CD
AM•FM
ON OFF TV
T APE
SA T•CABLE
SURROUND
ER
SOURCE
PRESET - PRESET +
VCR 1
VCR 2 DVD
/ C H +
CD
AM•FM
ON OFF TV
T APE
SA T•CABLE
VCR 1
VCR 2 DVD
/ C H +
CD
AM•FM
ON OFF TV
T APE
SA T•CABLE
