Raymarine Ray430 User Manual
Page 45
Description
Qty.
Symbol
Part No.
Side Chassis L
1
Transformer Bracket
1
Yoke Bracket
1
G263596-4
Yoke Knob W/Screw
2
G263806-1
Yoke Spacer
2
G261807-1
Internal Speaker
1
G263597-13
Heat Sink Rear
2
Gasket Rear
1
G263597-28
Terminal Block
1
G263648-21
Knob Spacer
2
Vol Spacer
2
Heat Sink (IC-1)
1
PCB Spacer
2
LCD 1
LCD101
G263648-24
6-7
