6-1
SECTION 6
6.1 PARTS LIST
***** LINEAR A PCB ASSEMBLY SECTION *****
Description Qty. Symbol Part No.
Linear A PCB Assembly 1 G263648-1
Capacitors
Stacked Metallized PPS Film, 0.001 µF 8 C301, 302, 303, 304, 313,
316, 318, 342
Stacked Metallized PPS Film, 0.0033 µF 2 C363, 365
Stacked Metallized PPS Film, 0.047 µF 2 C338, 339
Stacked Metallized PPS Film, 0.1 µF 2 C327, 362
Ceramic, 100 pF 13 C349, 350, 351, 352, 353
354, 355, 356, 357, 358,
359, 360, 361
Ceramic, 0.047 µF 1 C328
Elec., 1 µF/50WV 4 C306, 312, 320, 333
Elec., 2.2 µF/50WV 1 C314
Elec., 10 µF/16WV 17 C305, 309, 310, 315, 317,
319, 323, 324, 326, 330,
331, 334, 345, 346, 347,
348, 364
Elec., 47 µF/16WV 4 C307, 311, 321, 325
Elec., 47 µF/25WV 2 C343, 344
Elec., 100 µF/16WV 2 C308, 322
Elec., 100 µF/25WV 2 C336, 341
Elec., 220 µF/25WV 2 C337, 340
Elec., 1000 µF/35WV 1 C335
Tantalum, 1 µF/16WV 2 C329, 368
Resistors
Jumper, 0 ohm 1 R323
Metal Glaze, 1 ohm 2 R348, 349
Metal Glaze, 47 ohm 2 R317, 334
Metal Glaze, 68 ohm 2 R346, 350
Metal Glaze, 100 ohm 8 R301, 302, 303, 305,
307,309, 324, 326
