Description Qty. Symbol Part No.
Semiconductors (cont.)
Transistor, 2SA1298(Y) 1 Q207
Transistor, 2SC4116(Y) 1 Q208
Diode, 1N5401-B 1 D201
Diode, 1S1888A 9 D202, 203, 204, 205, 206,
207, 208, 209, 210
Miscellaneous
Relay, ME-1-12P (12V DC) 7 RY201, 202, 203, 204, 205,
206, 207
Connector, B26B-XADSS-N(LF)(SN) 1 CN201
Connector, TX14-30R-10ST-N1E 1 CN202
Connector, B5B-XH-A(LF)(SN) 2 CN203, 204
Connector, B4B-XH-A(LF)(SN) 1 CN206
Terminal Block, M116C-24 1 CN207
***** EL PCB ASSEMBLY SECTION *****
EL PCB Assembly 1
Capacitors
Stacked Metallized PPS Film, 0.0082 µF 1 C403
Elec., 1 µF/50WV 1 C402
Elec., 470 µF/25WV 1 C401
Coil
EL Transformer, EI-19(C995R) 1 T401
Resistors
Metal Glaze, 22 ohm 1 R402
Metal Glaze, 150 ohm 1 R403
Metal Glaze, 6.8 kohm 1 R401
Semiconductor
Transistor, 2SC2712(GR) 1 Q401
Miscellaneous
Connector, B2B-XH-A(LF)(SN) 1 CN401
6-4
