Description
Qty.
Symbol
Part No.
Miscellaneous (cont.)
Fiber, PCB
1
***** LINEAR B PCB ASSEMBLY SECTION *****
Linear B PCB Assembly
1
G263648-2
Capacitors
Stacked Metallized PPS Film, 0.001 µF
2
C205, 227
Stacked Metallized PPS Film, 0.01 µF
1
C219
Ceramic, 100 pF
7
C220, 221, 222, 223, 224,
225, 226
Ceramic, 0.1 µF
2
C207, 208
Elec., 10 µF/25WV
5
C214, 215, 216, 217, 218
Elec., 47 µF/25WV
3
C206, 209, 210
Elec., 220 µF/25WV
1
C204
Elec., 1000 µF/35WV
3
C201, 202, 203
Coil
Coil, EI-19(CZ99)
1
CH201
Resistors
Metal Glaze, 100 ohm
1
R213
Metal Glaze, 1 kohm
7
R202, 207, 208, 209, 210,
211, 214
Metal Glaze, 2.2 kohm
1
R212
Metal Glaze, 4.7 kohm
1
R203
Metal Glaze, 10 kohm
3
R215, 216, 217
Metal Film, 4.7 ohm (3W)
1
R201
Resistor Array, 10 kohm
1
RA201
Semiconductors
I.C., TA7805S(Q)
1
IC201
I.C., TA7808S(Q)
1
IC202
I.C., TD62307PG(J)
1
IC203
I.C., TLP181GB(V4-GB-TPR,F)
6
IC204, 205, 206, 207, 208,
209
Transistor, 2SC2712(GR)
1
Q201
Transistor, RN1410
3
Q202, 204, 205
Transistor, 2SA1162(Y)
1
Q203
6-3
