Page 32: 5. dvi source connections, Pre l iminar y
22
Runco PlasmaWall Owner’s Operating Manual
PRE
L
IMINAR
Y
Connecting Source
Components to the DHD
Controller
Connect your video sources to the DHD Controller as shown and described in the
sections that follow.
DVI Connections: See Figure 3-5.
Figure 3-5. DVI Source Connections
➤
Use the DVI inputs whenever possible. This ensures the highest
video quality because the signal is carried in the digital domain
throughout the entire signal path, from source component output
into the display.
Tip
DVI 1
HD1
HD2
G/Y
INPUTS
H
V
R/Pr
B/Pb
G/Y
H
V
R/Pr
B/Pb
DVI 2
Component Video
Pb
Pr
Y
Video
S-Video 2
S-Video 1
IR
1
2
3
TRIGGERS
DVI Source
(DVD Player or
HD Tuner with
HDMI or DVI out)
