Controls and functions, 1 vx-33d at a glance, Figure 2-1 . vx-33d front/bottom/side view – Runco VX VIDEO XTREME VX-33D User Manual
Page 21: Iminar, Vx-33d at a glance, 1. vx-33d front/bottom/side view, Pre l iminar y
Runco VX-33d Installation/Operation Manual
5
PRE
L
IMINAR
Y
2.1
VX-33d at a Glance
Figure 2-1 shows the key VX-33d components.
Figure 2-1. VX-33d Front/Bottom/Side View
1.
INTAKE VENT
2.
LENS OPENING
3.
RUNCO LOGO
The logo can be rotated to match the projector orientation: inverted (ceiling-mounted)
or upright. To rotate the logo, grip it at the sides, pull it away from the projector and
rotate it 180 degrees.
4.
CABLE OPENING
Pass cables through this opening.
5.
EXHAUST VENT
2. Controls and Functions
2
5
4
1
3
4
