3
1.3 Installing the H-UDI Port Connector on the User System
Table 1.3 shows the recommended H-UDI port connectors for the emulator.
Table 1.3 Recommended H-UDI Port Connectors
Connector Type Number Manufacturer Specifications
DX10M-36S Screw type 36-pin connector
DX10M-36SE,
DX10G1M-36SE
Hirose Electric Co., Ltd.
Lock-pin type
14-pin connector 2514-6002 Minnesota Mining &
Manufacturing Ltd. 14-pin straight type
Note: When designing the 36-pin connector layout on the user board, do not connect any
components under the H-UDI connector. When designing the 14-pin connector layout on
the user board, do not place any components within 3 mm of the H-UDI port connector.
1.4 Pin Assignments of the H-UDI Port Connector
Figures 1.1 and 1.2 show the pin assignments of the 36-pin and 14-pin H-UDI port connectors,
respectively.
Note: Note that the pin number assignments of the H-UDI port connector shown on the
following pages differ from those of the connector manufacturer. For the pin number
assignments of the SH7339, refer to the hardware manual.
