26
2.2.7 Performance Measurement Function
The emulator supports the performance measurement function.
1. Setting the performance measurement conditions
To set the performance measurement conditions, use the [Performance Analysis] dialog box
and the PERFORMANCE_SET command. When any line on the [Performance Analysis]
window is clicked with the right mouse button, the popup menu is displayed and the
[Performance Analysis] dialog box is displayed by selecting [Setting].
Note: For the command line syntax, refer to the online help.
(a) Specifying the measurement start/end conditions
The measurement start/end conditions are specified in the [Mode] drop-down list box in the
[Performance Analysis] dialog box. Three conditions can be set as shown in table 2.9.
Table 2.9 Conditions Specified in [Mode]
Item Description
Normal break Measurement is started by executing a program and ended when a
break condition is satisfied.
Break Condition 1 -> 2 Measurement is started from the satisfaction of the condition set in
Break Condition 1 to the satisfaction of the condition set in Break
Condition 2.
Break Condition 2 -> 1 Measurement is started from the satisfaction of the condition set in
Break Condition 2 to the satisfaction of the condition set in Break
Condition 1.
