51
Appendices
Specifications
VGA-7: V-Guitar Amplifier
● Rated Power Output
130 W (65 W + 65 W)
● Patches
160 (Preset: 80 + User: 80)
● Nominal Input Level (1 kHz)
INPUT HIGH: -10 dBu/470 k Ω
INPUT LOW: 0 dBu/330 k Ω
EXT IN: +4 dBu
● Nominal Output Level
LINE OUT: +4 dBu
* 0 dBu = 0.775 Vrms
● Speakers
(30 cm + Horn Tweeter) x 2
● Display
8 segments 3 characters LED
● Controls
COSM GUITAR section
TYPE button
PICKUP button
TUNING button
CAPO button
COSM AMPLIFIER section
AMP TYPE button
GAIN knob
VOLUME knob
EQUALIZER: BASS knob
MIDDLE knob
TREBLE knob
PRESENCE knob
SPEAKER TYPE button
EFFECTS section
EFX: EFX button
SELECT button
Control knob x 2
DELAY: DELAY button
TAP TEMPO button
FEEDBACK knob
LEVEL knob
CHORUS: CHORUS button
INTENSITY knob
REVERB: REVERB button
LEVEL knob
Master section
TUNER button
VARIATION/EDIT button
GK button
SYSTEM button
WRITE button
PRESET/USER button
BANK ▼ button
BANK ▲ button
NUMBER ▼ button
NUMBER ▲ button
MANUAL button
Direct number button (A/B, 1/6–5/10)
TUNER indicator
MASTER knob
POWER switch
● Connectors
GK IN connector
INPUT jacks (HIGH, LOW)
PHONES jack
LINE OUT jacks (L(MONO)/R)
EXT IN jacks (L(MONO)/R)
EXP PEDAL jack
EFX jack
DELAY jack (TIP: ON/OFF, RING: TAP TEMPO)
CHORUS jack
REVERB jack
MIDI connectors (IN, OUT/THRU)
