27 RF-RBWS02
Specifications
Sender
Speaker
Connecting a device • When you try to join a device to a network that has too
many nodes, the device will stay in joining mode until it
times out (30 second timeout). Upon timeout the unit
should be on and will flash the power ring LED in a slow
blink indicating it is not connected to the network.
When trying to change the
source on a Rocketfish unit
the Power LED flashes 5
times. • Your RF-RBKIT sender is in four channel lock mode. By
design, these channels are not available for access by
other receivers as they form the rears/surrounds of your
Home Theater system. If you do wish to use them, then
you should remove the four channel lock mode by
moving the switch on the back of the sender to disable
four channel lock mode. Both sources will then be
available for all receivers.
Power supply 5 V, 600 mA
Maximum line-level input
signal level
2.0 Vrms
Maximum line-level output
signal level
1.0 Vrms
Output loading 10 K Ohm
Signal-to-noise ratio 90 dB
Dimensions (WxHxD)
4.72 x 3.15 x 0.91 inches
(120 x 80 x 23 mm)
Weight
4.1 oz.
(116 g)
Power supply (DC to AC adapter) 15 V, 1.5 A
Battery power 8 C-cells (UM-2) (Alkaline or NiMH)
Signal-to-noise ratio 90dbA +/-3DbA
Problem Solution
