Chapter 4 Applications Development Procedure Overview
- 65 -
4.2.3 Configurator Execution
When using HEW, select "Build all," which enables the user to execute the procedures described in 4.2.3,
"Executing the Configurator," and 4.2.4, "System Generation."
Execute the configurator cfg308 to generate system data definition files (sys_rom.inc, sys_ram.inc), include files
(mr308.inc, kernel_id.h), and a system generation procedure description file (makefile) from the configuration
file.
A> cfg308 -mv lbp.cfg
MR308 system configurator V.4.00.06
Copyright 2003,2005 RENESAS TECHNOLOGY CORPORATION
AND RENESAS SOLUTIONS CORPORATION ALL RIGHTS RESERVED.
MR308 version ==> V.4.00 Release 01
A>
Figure 4.4 Configurator Execution
4.2.4 System generation
Execute the make command 43 to generate the system.
A> make -f makefile
as308 -F -Dtest=1 crt0mr.a30
nc308 -c task.c
ln308 @ln308.sub
A>
Figure 4.5 System Generation
4.2.5 Writing ROM
Using the lmc308 load module converter, convert the absolute module file into a ROM writable format and then
write it into ROM. Or read the file into the debugger and debug it.
43 There are two types of make commands, one of which conforms to the MS-DOS standard, and the other conforms to or is compliant with
the UNIX standard. MR308 accepts only the make command that conforms to or is compliant with the UNIX standard. When using MS-DOS,
use a UNIX compatible make command (e.g., the make command included with the C compiler from Microsoft Corporation). For details
about the usefulness of UNIX compatible make commands, refer to the release notes from Renesas. The description in this chapter is made
for the case where a UNIX compatible make command is executed, as an example.
