Chapter 6 Using Configurator
- 96 -
6.1 Configuration File Creation Procedure
When applications program coding and startup program modification are completed, it is then necessary to reg-
ister the applications program in the MR308 system.
This registration is accomplished by the configuration file.
6.1.1 Configuration File Data Entry Format
This chapter describes how the definition data are entered in the configuration file.
Comment Statement
A statement from '//' to the end of a line is assumed to be a comment and not operated on.
End of statement
Statements are terminated by ';'.
Numerical Value
Numerical values can be entered in the following format.
1. Hexadecimal Number
Add "0x" or "0X" to the beginning of a numerical value, or "h" or "H" to the end. If the value begins with
an alphabetical letter between A and F with "h" or "H" attached to the end, be sure to add "0" to the
beginning. Note that the system does not distinguish between the upper- and lower-case alphabetical
characters (A-F) used as numerical values.
57
2. Decimal Number
Use an integer only as in '23'. However, it must not begin with '0'.
3. Octal Numbers
Add '0' to the beginning of a numerical value of 'O' or 'o' to end.
4. Binary Numbers
Add 'B' or 'b' to the end of a numerical value. It must not begin with '0'.
Table 6.1 Numerical Value Entry Examples
0xf12
0Xf12
0a12h
0a12H
12h
Hexadecimal
12H
Decimal 32
017
17o
Octal
17O
101110b
Binary
101010B
It is also possible to enter operators in numerical values. Table 6.2 lists the operators available.
57 The system distinguishes between the upper- and lower-case letters except for the numbers A-F and a-f.
