6
INSTALLATION
MOUNTING THE PHONE
You can place the ET-1119’s base on a
desk or table, mount it on a standard
wall plate, or mount it directly on a wall.
Choose a location that is:
• near an AC outlet
• near a telephone line jack
• out of the way of normal activities
• away from electrical machinery,
electrical appliances, metal walls or
filing cabinets, wireless intercoms,
alarms, and room monitors
• away from other cordless phones
The base’s location affects the hand-
set’s range. If you have a choice of sev-
eral locations, try each to see which
provides the best performance.
Cautions:
You must use a Class 2
power source that supplies
9V DC and delivers at least
500 mA. Its center tip must be set to
positive and its plug must fit the ET-
1119's
DC IN 9V jack. The supplied
adapter meets these specifications.
Using an adapter that does not meet
these specifications could damage
the ET-1119 or the adapter.
• Always connect the AC adapter to
the ET-1119 before you connect it to
AC power. If you should ever need
to disconnect the power, disconnect
the adapter from AC power before
you disconnect it from the ET-1119.
• The supplied RadioShack adapter
was designed specifically for your
ET-1119. Use only the supplied
adapter.
Notes:
• Your telephone connects directly to
a modular phone line jack. If your
phone line jack is not a modular
jack, you can update the wiring
yourself, using jacks and adapters
available from your local
RadioShack store. Or, you can let
the telephone company update the
wiring for you.
• The USOC number of the jack to be
installed is RJ11C, or RJ11W for a
wall plate jack.
On a Desk
Follow these steps when you place the
base on a desk or table.
1. Insert the bracket’s tabs into the
base’s upper tab slots, then press
down on the bracket’s clips and
insert them into the clip slots.
!
