Basics
40
2
When using the Wireless LAN Interface (option) in 802.11 Ad hoc Mode
Make sure to set 802.11 Ad hoc Mode, when SSID is necessary in Ad hoc
Mode. If encrypted transmission is used, make sure to set WEP after SSID.
Note
❒ You can set the 802.11 Ad hoc Mode from your computer when setting
SSID (Network Name).
❒ The network administrator must check the environment and set the Com-
munication mode, WEP key and SSID correctly. For details on settings, see
“Using the IEEE 802.11b (Wireless LAN)” in the Network Printing Guide.
❒ Characters used for setting SSID are which are case-
sensitive. You can enter up to 32 characters.
❒ You can also set 802.11 Ad hoc mode from the Web browser. For details on
settings, see the Network Printing Guide.
A Make sure that [Network] is selected, and then press [LAN Type] key.
B Press the [IEEE 802.11b] key, and then press the [OK] key.
C Press the [IEEE 802.11b] key.
D Press the [Communication Mode] key.
E Press the [802.11 Ad hoc] key, and then press the [OK] key.
F Press the [Channel] key.
G Use the number keys to enter the channel to be used, and then press the
[OK] key.
H Press the [SSID Setting] key.
I Press [Enter SSID] and enter the SSID, and then press the [OK] key.
J Press the [OK] key.
