21
8. When this emulator is used without connecting to the user system, ensure that the SW1 jumper
pin is inserted to [OFF]. Failure to do so will damage the emulator product, user system
interface cable, and user system.
9. To connect the emulator to the user system, ensure that the SW1 jumper pin is inserted to
[ON]. Failure to do so will damage the emulator product, user system interface board, and user
system.
10. Do not connect a 5-V signal to any pin, including the USB pins. Incorrect usage will cause
damage to the emulator product, user system interface board, and user system.
