2
CAUTION
Use an IC149-120-043-B51 socket (manufactured by
YAMAICHI ELECTRONICS Co., Ltd.) for the TFP-120 package
IC socket on the user system.
Table 1 HS1653ECN61H Components
No. Component Quantity Remarks
1 User system interface
board 1
2 IC socket 1 For the TFP-120 package (to be mounted on the user
system)
3 Socket cover 1 For installing a TFP-120-packaged MCU
4 Screw (M2 x 12 mm) 4 For fastening cable head (with four flat washers)
5 Screw (M2 x 8 mm) 4 For installing a TFP-120-packaged MCU (with four flat
washers)
6 Spacers (2.6MP x 25 mm) 2
7 Spacers (2.6MQ x 16 mm) 4
8 User’s manual 1 User’s manual for HS1653ECN61H (this manual)
