Renesas H8SX/1653 User Manual
Page 18
7
2.2
Exchanging the Spacer of the Evaluation Chip Board
While the user system interface board is connected to the user system, be careful not to apply
load.
Exchange the spacer (2.6MP
×
10 mm) of the evaluation chip board with another spacer (2.6MP
×
25 mm) provided for the user system interface board.
Evaluation chip board
Spacer
(2.6MP
×
25 mm)
Figure 3 Exchanging the Spacer
