13
2.7
Using the Emulator without Connecting User System
WARNING
Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE BOARD
is connected to or removed from any part. Before
connecting, make sure that pin 1 on both sides are correctly
aligned. Failure to do so will result in a FIRE HAZARD and
will damage the user system and the emulator product or
will result in PERSONAL INJURY. The USER PROGRAM will
be LOST.
CAUTION
When this emulator is used without connecting to the
user system, ensure that the SW1 jumper pin is inserted to
[OFF]. Failure to do so will damage the emulator
product, user system interface cable, and user system.
Attach the provided spacers (2.6MQ x 16 mm) to four positions on the user system interface board
not to apply loads to the connector (CN1) on the board.
