6.2 When the Emulator Debugger Does Not Start Up Properly
(1) When the LED Display of PC4701 is Abnormal
Table 6.1 LED's abnormal display and its checkpoints
Error
Connection to
the target system
Checkpoint
LEDs do not light up.
All LEDs remain lit.
The POWER LED of
"STATUS OF TARGET"
does not light up.
The CLOCK LED of
"STATUS OF TARGET"
does not light up.
The RESET LED of
"STATUS OF TARGET"
does not go out.
-
-
Connected
Disconnected
Connected
Connected
Recheck that the power cable is connected to the
PC4701.
See the PC4701 User's Manual.
(1) Recheck that the connection between the
PC4701 and this product.
See "3.4 Connecting the PC4701 and
Emulation Pod" (page 27).
(2) Recheck that the connection between the
PC4701 and the M30100T3-RPD-E.
See "3.5 Connecting the Pod Probe (page 29).
Check that power is properly supplied to the target
system and that the target system is properly
grounded.
(1) Check that both the main and sub clocks of the
emulator debugger are not set to "EXT".
See the CLK command of the emulator
debugger.
(2) Check that the oscillation circuit in the
M30100T3-RPD-E is oscillating.
See "3.2 Selecting Clock Supply and Replacing
Oscillator Circuit Boards (page 23).
(1) Check that the oscillation circuit in the target
system is oscillating properly.
(2) Check that the switches of the pod probe
interface board are correctly set.
See the user's manual of pod probe.
Check that the reset pin of the target system is
pulled up.
