RCA X3000 - Manual (Page 17)

EN
5. - USB connector
6. AV OUT (Green)/
- Ouput audio and video signal when the
audio and video cable is connected.
- Insert the headphones here.
7. - In the main menu mode, press and
hold to turn on/off the unit.
- In playback mode, press to stop playback.
- In menu mode, press to return to previous
menu.
8. - - Press to decrease volume.
- Press to go to the previous page during file
browsing.
9. M - Press to enter menu setting mode
10. + - Press to increase volume.
- Press to go to the next page during file
browsing.
11. - Press to record in audio/video
recording mode.
• I n playback mode, press to switch
between speaker and headphone
output.
• In AV recording mode, press in to
switch between speaker and headphone
output.
12. DC - Connects the power cord for battery
charging.
13. Push to eject compact flash card.
14. Compact flash card slot
15. LCD ON/AV OUT - Slide to select between
LCD output or AV output.
General Controls
6
