Dominion SX Serial RJ-45 Pinouts
To provide maximum port density and to enable simple UTP (Category 5) cabling, Dominion SX
provides its serial connections via compact RJ-45 ports. However, no widely adopted industry-
standard exists for sending serial data over RJ-45 connections.
The following tables list the RJ-45 pinouts for the RJ-45 connector, which is on the back of the
DSX.
Table 76 Dominion SX RJ-45 Serial Pinouts and Signals
RJ-45
PIN
SIGNAL
1 RTS
2 DTR
3 TxD
4 GND
5 Signal
GND
6 RxD
7 DSR
8 CTS
Go to the following link to find the latest information about the Dominion SX serial
pinouts (RJ-45).
DB9F Nulling Serial Adapter Pinouts
Table 77 DB9F Nulling Serial Adapter Pinouts
RJ-45
(F
EMALE
)
DB9
(F
EMALE
)
1 8
2 1,
6
3 2
4 SHELL
5 5
6 3
7 4
8 7
