Ricoh Monochrome PoCl Camera Link Camera FV-L030B1 User Manual

Page 25

25/32

FV-L030B1
User’s Guide Rev. 1.01

4.4.2

Descriptions of the Camera Control Commands

(The underline settings are the factory default settings)

Command No.

Command Descriptions

10H:

MOD1[7

[Camera function mode setting 1] Initial data: 09H

Sets the following camera function mode.

D[7

D7:

Continuous / Trigger Mode

0: Auto

1: Manual

D6:

Trigger Polarity

0: Positive

1: Negative

D5:

Trigger Mode

0: Edge Preset

1: Pulse Width

D4:

Binning Mode

0: OFF (Normal)

1: ON (Binning)

D3:

Scanning Mode

0: Full scanning

1: Partial scanning

D2 to D0:

Reset Mode

000: Non-Reset

001: V-Reset

010~111: No function

(Prohibited setting. Please do not use these)

When D7 is set to “0: Auto”, a camera will detect its operational mode based on the input trigger signal.

If the input trigger signal is kept at high, the camera operates in the continuous mode, assuming the trigger polarity

is set to positive.

11H:

MOD2[7

[Camera function mode setting 2] Initial data: 32 (20H)

Sets the following camera function modes.

D[7

HD / VD direction

00H: SP2 and SP3 as inputs

01H: SP2 and SP3 as outputs

10 to 11H: (Prohibited setting. Do not set these values)

D6 to D5

Frame rate

00H: 60fps

01H: 90fps

10H: 30fps

11H: No function

Smear Half Reduction

0: OFF

1: ON

Function Mode

0: Trigger Mode

1: Continuous Mode

D2 to D0:

Partial Scanning

000: Full scanning

001: 1/2 partial scanning

010: 1/4 partial scanning

111: Variable partial scanning

011~110: No function (Prohibited setting. Do not set these values)

Function mode is enabled when the “Continuous/Trigger” mode selection (MOD[7] is manual (set as 1).

No video output without the trigger signal input while the camera works with the trigger mode.
