Renesas User System Interface Cable HS36049ECH61H User Manual
Page 31
17
Figure 10 shows the system clock oscillator on the user system interface cable and the subclock
input specifications.
To E6000
emulator
System clock oscillator
To E6000
emulator
Subclock oscillator
R2 270
R1 1 M
HCU04
HCU04
OSC1
OSC2
Ω
Ω
R6 470 k
R5 3.3 M
HCU04
HCU04
HCU04
X1
X2
Ω
Ω
R12 2.2 k
Ω
R13 10 k
Ω
HCU04
Figure 10 System Clock Oscillator and Subclock Input Specifications
