6

Cable body connector

User system interface cable

CTS screws (M3 x 6 mm)

Expansion I/O board

USER

INTERF

AC

E C

AB

L

E600

0EM

ULAT

O

E6000

Figure 3 Connecting User System Interface Cable to Expansion I/O Board
